The DW DW8500W is a gasoline generator originating from a leading and reputable generator
company in China. Designed for three-phase operation, this unit boasts a maximum power output of
4.4 kVa. It’s an efficient machine with a fuel consumption rate of just 0.55 liters per hour and a 15-
liter fuel tank capacity. The generator weighs 38 kilograms and does not come with protective casing
or transport wheels.
Features
• Engine: Single-cylinder, four-stroke engine with overhead valves and air cooling.
• Starting Mechanism: Equipped with an electric starter and a manual starter for easy start-up.
• Fuel Efficiency: Consumes only up to 1.15 l/h, making it highly fuel-efficient.
• Long-Running: Can operate up to 13 hours on a single tank.
• Safety Measures: Automatic shut-off system in case of a short circuit or low oil level.
• AVR Automatic Voltage Regulation: Ensures stable power supply.
• Intelligent Throttle Technology: Adjusts speed according to the load.
Technical Specifications
• Type: Synchronous generator
• Phase: Three-phase
• Max Power: 8500W
• Voltage: 230V/380V/12V
• Rated Current: 8.3 A
• Frequency: 50 Hz
• Voltage Stability: ±1%
• Protection Level: IP 23
• Outlets: Three single-phase 220V, one three-phase 380V, and one DC 12V
• Dimensions (LxHxW): 600 x 440 x 430 mm
• Weight: 38 kg
• Engine Type: Four-stroke, single-cylinder with overhead valves and air cooling
• Displacement: 196 cc
• Engine Speed: 5000 rpm
• Tank Capacity: 15 l
• Fuel Consumption: 1.15 l/h
• Oil Capacity: 0.6 l
• Autonomous Operation Time: Up to 12 hours
• Noise Level: 65 dB
• Safety Measures: Overload protection, oil level engine protection
• Fuel Level Sensor: Yes
• Start Method: Electric starter
• Shock Absorbers: Yes
The DW DW8500W gasoline generator is a reliable and efficient choice for construction and industrial
use, offering a range of features designed for performance and safety.
